ATC200X 86-87

This section allows you to search for
all parts relevant to Honda ATC200X 86-87 models.

ATC200X, 2nd generation Introduced 1986, ends 1987, Features:

• Model Code for 86-87 models “HB5”.
• 5 speed manual clutch transmission.
• 23.5x8x11 low pressure tyre front. 22x11x8 rear.
• Tyre pressure front 0.23 kg/cm2 (3.3 PSI )1895 mm
  dia.
• Tyre pressure rear 0.17 kg/cm2 (2.4 PSI )1745 mm
  dia.
• Front fork oil capacity ??.
• Length?? mm, Width ??mm, Height ??mm.
• Engine bore 65mm, Stroke 57.8mm. CR 9.6:1 Displacement 191.8cc.
• Carb Keihin?? ,, main jet ??.
• Engine number below magneto cover in front of gear shift shaft.
• Frame number located on steering head stock left side.
• Engine Oil capacity ??ltr (change) ??ltr (bone dry).
• Fuel tank capacity ??.(ltr main ltr Reserve).
• CDI Ignition.
• Plug gap 24-28 thou (0.6-0.7mm).
• Plug NGK DR8ESL.
• Valve clearance (cold) 0.05mm.
