ATC250R 81-82

The Honda ATC250R, first generation Introduced 1981, ends 1982, Features:

• Model Code for 81-82 models “961”.
• 5 speed manual clutch transmission.
• low pressure tyres. 22x11x8.
• Tyre pressure front 0.15kg/m2 (2.2 PSI )1760 mm dia.
• Tyre pressure rear 0.15 kg/m2 (2.2 PSI )1760 mm dia.
• Front fork oil capacity 174cc.
• Length 1795mm, Width 1075mm, Height 1040mm Weight 137kg.
• Engine bore 70mm, Stroke 64.4mm. CR 6.6:1 Displacement 248cc.
• Carb Keihin PE23A, main jet #158.
• Engine number below clutch cover in front of gear shift shaft.
• Frame number located on steering head stock left side.
• Engine Oil capacity 1.1ltr.
• Fuel tank capacity 8.4ltr.(6.5ltr main 1.9ltr Reserve).
• CDI Ignition.
• Plug gap 28-31 thou (0.7-0.8mm).
• Plug NGK B8ES.
