ATC250R 85-86

The Honda ATC250R, 3nd generation Introduced 1985, ends 1987, Features:

• Model Code for 85-86 models “HA2”.
• 6 speed manual clutch transmission.
• low pressure tyres. 23x8x11 front. 20x10x9 rear.
• Tyre pressure front 0.30 kg/cm2 (4.3 PSI )?? mm dia
• Tyre pressure rear 0.25 kg/cm2 (3.6 PSI )?? mm dia
• Front fork oil capacity (85)400cc, (86)465cc.
• Length (85)1895 mm/ (86) 1905mm, Width (85)1120 mm/(86)1130
  mm Height (85)1090 mm/(86)1085mm, Weight (85) 132kg/ (86) 131kg.
• Engine bore 66mm, Stroke 72mm. CR8.0:1 Displacement 246cc
• Carb Keihin (85)PE37A, (86-)PJ03A, main jet (85)#142 (86-)#145.
• Engine number left side of engine above gear shift shaft.
• Frame number located on steering head stock left side.
• Engine Oil capacity 0.61ltr (change) 0.70ltr (bone dry)
• Fuel tank capacity 9.8ltr, (7.8ltr main 2.0ltr Reserve).
• CDI Ignition,
• Plug gap 24-28 thou (0.6-0.7mm)
• Plug NGK BR9ES (subject to altitude and temperature)
