ATC110

This section allows you to search for
all parts relevant to Honda ATC110 79-85 models

ATC110 , introduced 1979, ends 1985, Features:

• Model Code for 79-85 models “943”.
• 4 speed auto clutch transmission High & Low range sub transmission.
• 22x11x8 tyre, split rim, 3 bolt 79-81, 4 bolt 82-85.
• Tyre pressure 0.15 kg/cm2 (2.2 PSI ) 1742mm dia.
• Length 1600mm, width 950mm, Height 940mm, Weight 107kg.
• Engine bore 52mm, Stoke 49.5mm, CR 8.2:1 Displacement 105.1cc.
• Carb Keihin PB20A, main jet #82, slow #35.
• Engine number located below starter and behind gear change shaft.
• Frame number located on steering head stock left side.
• Engine Oil capacity .9 ltr.
• Fuel tank capacity (79-82) 6.0ltr, (5.1ltr main, .9ltr reserve).
• Fuel tank capacity (83-85) 6.5ltr, (5.5ltr main, 1.0ltr reserve).
• Point gap 0.3 – 0.4 mm (12 to 16 thou) CDI 82 on.
• Plug gap 0.6 – 0.7 mm (24 to 28 thou).
• Plug NGK D8HS.
• Valve clearance (cold) 0.05mm.
