ATC185/S

The Honda ATC185 , was introduced 1980, ends 1983, Features:

• Model Code for 80-83 models “958”
• 5 speed auto clutch transmission
• 25x12x9 (ATC185) 22x11x8 tyre, (ATC185S) split rim,
• Tyre pressure 0.15 kg/cm2 (2.2 PSI ) (1948mm dia
  185) (1743mm 185S)
• Length (ATC185) 1820mm, Width 1110mm, Height 995mm
• Length (ATC185S) 1720mm, Width 1000mm, Height 965mm, 125.5kg
• Engine bore 63mm, Stroke 57.8mm. CR 8.0:1 Displacement 180 cc
• Carb Keihin PD35D, main jet 95
• Engine number below pull starter in front of gear shift shaft
• Frame number located on steering head stock left side
• Engine Oil capacity .95ltr (change) 1.35ltr (bone dry)
• Fuel tank capacity 8.7ltr
• CDI Ignition,
• Plug gap 24-28 thou (0.6-0.7mm)
• Plug NGK DR8ESL
• Valve clearance (cold) 0.05mm
