ATC70 78-85

This section allows you to search for all parts relevant to Honda ATC70 78-85 models.

ATC70, 2nd generation introduced 1978, ends 1985, Features:

• Model Code for 78-85 models “957”.
• 3 speed auto clutch transmission(78-81) 4 speed (82-85).
• 16x8x7 low pressure tyres, SPWAMULASS (Water,Mud,Land,Sand,Snow).
• Tyre pressure 0.2 kg/cm2 (3.0 PSI ).
• Length 1300mm, width 800mm, Height 785mm, Weight 74kg.
• Engine bore 47mm, Stoke 41.4mm, CR 7.5:1 Displacement 72cc.
• Carb Keihin PB38A to 83, PC38A 84-85, main jet 58.
• Engine number located below starter and behind gear change shaft.
• Frame number located on steering head stock left side.
• Engine Oil capacity .8 ltr.
• Fuel tank capacity 4.0ltr, 3.2ltr main and .8ltr reserve.
• Point gap 0.3 – 0.4 mm (12 to 16 thou).
• Plug gap 0.6 – 0.7 mm (24 to 28 thou).
• Plug NGK C7HS.
• Valve clearance (cold) 0.05mm.
